SuPyMode#

This project aims to develop an useful tool design and optimize fiber optic tapered component. SuPyMode is a Python library linked to a c++ core allowing for a flexible interface and fast computing core. The library also aims to offer the end-user a great vizual tools for data analysis. To this day, SuPyMode as been proven a useful tool to develop very-short 2x1 and 3x1 modally specific photonic lantern with very low loss and cross-talk.

Features#

  • Fast and efficient simulation of fiber optic tapered components.

  • User-friendly interface for easy integration into existing workflows.

  • Comprehensive visualization tools for data analysis and interpretation.

Installation#

SuPyMode is available on PyPI and Anaconda. Install it with:

pip install SuPyMode
conda install SuPyMode

See the online documentation for detailed usage and additional examples.

Quick example#

Below is a short example computing the mode propgation in a simple fiber.

from SuPyMode.workflow import Workflow, fiber_loader, Boundaries, BoundaryValue, DomainAlignment

wavelength = 1550e-9

fiber = fiber_loader.load_fiber('SMF28', clad_refractive_index=1.4444, remove_cladding=False)

boundaries = [
   Boundaries(right=BoundaryValue.SYMMETRIC, top=BoundaryValue.SYMMETRIC),
   Boundaries(right=BoundaryValue.SYMMETRIC, top=BoundaryValue.ANTI_SYMMETRIC)
]


workflow = Workflow(
   fiber_list=[fiber],             # List of fiber to be added in the mesh, the order matters.
   wavelength=wavelength,          # Wavelength used for the mode computation.
   resolution=80,                  # Number of point in the x and y axis [is divided by half if symmetric or anti-symmetric boundaries].
   x_bounds=DomainAlignment.LEFT,  # Mesh x-boundary structure.
   y_bounds=DomainAlignment.BOTTOM,# Mesh y-boundary structure.
   boundaries=boundaries,          # Set of symmetries to be evaluated, each symmetry add a round of simulation
   n_sorted_mode=3,                # Total computed and sorted mode.
   n_added_mode=2,                 # Additional computed mode that are not considered later except for field comparison [the higher the better but the slower].
   plot_geometry=True,             # Plot the geometry mesh before computation.
   auto_label=True,                # Auto labeling the mode. Label are not always correct and should be verified afterwards.
   itr_final=0.05,                 # Final value of inverse taper ratio to simulate
   index_scrambling=0              # Scrambling of refractive index value in order to lift mode degeneracy [useful for some analysis]
)

workflow.superset.plot(plot_type='field', itr_list=[1.0, 0.1])

workflow.superset.plot(plot_type='index')

workflow.superset.plot(plot_type='normalized-coupling')

workflow.superset.plot(plot_type='adiabatic')

Building from source#

For development or manual compilation, clone the repository and run:

git submodule update --init
mkdir build && cd build
cmake ../ -G"Unix Makefiles"
sudo make install
cd ..
python -m pip install .

Testing#

Run the unit tests with:

pip install SuPyMode[testing]
pytest

Citing SuPyMode#

If you use SuPyMode in academic work, please cite:

@article{de2024supymode,
   title={SuPyMode: an open-source library for design and optimization of fiber optic components},
   author={de Sivry-Houle, Martin Poinsinet and Becerra Deana, Rodrigo Itzamna and Virally, St{\'e}phane and Godbout, Nicolas and Boudoux, Caroline},
   journal={Optics Continuum},
   volume={3},
   number={2},
   pages={242--255},
   year={2024},
   publisher={Optica Publishing Group}
}

Contact#

For questions or contributions, contact martin.poinsinet.de.sivry@gmail.com.
